300W Explosion Proof LED Flood Light IECEx Portable Tripod Mount Temporary 36000lm IP67 Copper-Free Aluminum Alloy
제품 상세 정보:
| 원래 장소: | 중국 광둥 |
| 브랜드 이름: | Fins board, BOCAQ |
| 인증: | CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI |
| 모델 번호: | EPFL-300W-포트 |
결제 및 배송 조건:
| 최소 주문 수량: | 10개 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 박스 package+ 버블 또는 맞춤화되곤 것처럼 |
| 배달 시간: | 10-15일 또는 확인 |
| 지불 조건: | T/T, 서부 동맹 |
| 공급 능력: | 5000pcs/월 |
|
상세 정보 |
|||
| 힘: | 300W | 광속: | 36000lm |
|---|---|---|---|
| 효능: | 120lm/w | 색온도: | 5000K (쿨 화이트) |
| 빔 각도: | 90° | 입력 전압: | AC 100-277V 50/60Hz |
| LED 칩: | 브리지룩스 SMD 3030 | IP 등급: | IP67 |
| 하우징 재료: | 에폭시 코팅 처리된 구리가 함유되지 않은 알루미늄 합금 | 렌즈 재질: | 강화유리 5mm |
| 작동 온도: | +55' C에 대한 -40' C | 인증: | IECEx Ex d IIC T6 Gb |
| 수명: | ≥50,000시간 L70 | 보증: | 5년 |
| 강조하다: | 300W explosion proof LED flood light,portable tripod mount explosion proof light,36000lm IP67 explosion proof lighting |
||
제품 설명
300W Explosion Proof LED Flood Light - IECEx Portable Tripod Mount
High-performance temporary lighting solution delivering 36000 lumens with IECEx certification for hazardous area applications. Features copper-free aluminum alloy construction and IP67 protection for extreme industrial environments.
Key Features
- 300W High Power Output - 36000lm total luminous flux with 120lm/W efficacy, replacing traditional HID equivalents with significant energy savings
- IECEx Ex d Certified - IECEx Ex d IIC T6 Gb for hazardous gas and dust atmospheres
- Robust Copper-Free Aluminum Alloy Housing - Copper-Free Aluminum Alloy with Epoxy Coating with corrosion-resistant coating for long-term durability
- IP67 Protection - Fully sealed against environmental ingress, suitable for the harshest industrial environments
- 5mm Tempered Glass Lens - High-transmittance safety glass with impact resistance rating
- Bridgelux SMD 3030 LEDs - Premium LED chips delivering stable 5000K (Cool White) light with excellent uniformity
- 90° Beam Angle - Focused beam for targeted work zone illumination for industrial hazardous area applications
- Universal Voltage Input - AC 100-277V 50/60Hz compatible with global electrical systems
- Multiple Mounting Options - Adjustable bracket, pole mount, and ceiling mount configurations included
- 5-Year Warranty - Backed by ≥50,000 hours L70 lifespan testing
- Portable Tripod System - Quick-deploy adjustable tripod stand (1.5m-3m) with lockable wheels, deployable by a single operator in under 5 minutes
- Rapid Deployment - Tool-free assembly with quick-connect bracket system, ideal for plant turnaround and shutdown scenarios
Applications
- Temporary lighting for plant turnarounds, maintenance, and emergency response
- Oil refineries and petrochemical processing plants
- Offshore drilling platforms and FPSO vessels
- Chemical storage warehouses and mixing facilities
- Gas compressor stations and LNG terminals
- Paint spray booths and solvent handling areas
Technical Specifications
| Model Number | EPFL-300W-PORT |
|---|---|
| Power Consumption | 300W |
| Luminous Flux | 36000lm |
| Efficacy | 120lm/W |
| Color Temperature | 5000K (Cool White) |
| Beam Angle | 90° |
| Input Voltage | AC 100-277V 50/60Hz |
| LED Chip | Bridgelux SMD 3030 |
| IP Rating | IP67 |
| Housing Material | Copper-Free Aluminum Alloy with Epoxy Coating |
| Lens | Tempered Glass 5mm |
| Operating Temperature | -40°C to +55°C |
| Mounting | Adjustable Bracket / Pole Mount / Ceiling Mount |
| Certification | IECEx Ex d IIC T6 Gb |
| Lifespan | ≥50,000 Hours L70 |
| Warranty | 5 Years |
ECER delivers explosion proof LED flood lights that combine cutting-edge LED technology with rigorous safety engineering. Each unit undergoes 100% factory testing including pressure testing of the explosion-proof enclosure and photometric verification.
For bulk orders, OEM/ODM customization, or technical inquiries, please contact our sales team.
